Belden 7805R 008100 Coaxial Cables 24.5AWG SOLID SH 100ft SPOOL GRAY - WAVE-AudioVideoElectric

Belden 7805R 008100 Coaxial Cables 24.5AWG SOLID SH 100ft SPOOL GRAY

by Belden
$153.66
SKU 7805R 008100
Product Specifications
Manufacturer: Belden Wire and Cable
Conductor/Pair Count: 1
AWG Gauge Size: 24.5 AWG
Conductor Type (Solid/Stranded): Solid
Conductor Material: Copper
Jacket Material
Jacket Color Gray (Slate)
UL Compliance
ROHS Compliance Compliant
Shielded Shielded
Shield Type/Construction
Dielectric Material
Fire/Flammability Rating
Temp Rating/Max Temp '+ 75 C
Voltage Rating:
Unit Weight in kg: 771.107 g
Unit Weight in Lbs: 1.6964354
Coax Type RG-174/U
Mil Spec


7805R Data Sheet
