BELDEN # 9461 060U1000 - Multi-Pair Cable, 1 Pair, 22 AWG, 7x30 Strands, Tinned Copper, PE Insulation, PVC Jacket - Price Per 1000 Feet

Product Specifications

Manufacturer:	Belden Wire and Cable
Conductor/Pair Count:	1 PAIR
AWG Gauge Size:	22 AWG (AMERICAN WIRE GAUGE)
Conductor Type (Solid/Stranded):	STRANDED CONDUCTOR
Conductor Material:	Tinned Copper
Jacket Material
Jacket Color
UL Compliance	UL LISTED ART 800
ROHS Compliance
Shielded	YES
Shield Type/Construction	FOIL SHIELDED - ALUM/MYLAR
Dielectric Material
Fire/Flammability Rating	GENERAL PURPOSE
Temp Rating/Max Temp
Voltage Rating:
Unit Weight in kg:
Unit Weight in Lbs:
Coax Type
Mil Spec

Spec Sheet

9461 Data Sheet
